Advantages
Using American microcomputer control and processing technology, semiconductor laser sensor technology and imported air pump, it has the characteristics of multi-function, high measurement accuracy, fast speed, easy to carry and simple operation.
Large storage space, can store 20000 groups of data, can use U disk to export data.
With Bluetooth printer, the test results can be printed.
Application
The instrument can simultaneously measure the number of dust particles with multiple particle sizes by one sampling. The product has been widely used in the following scenarios:
Clean room testing of electronic manufacturing enterprises;
Field detection and leakage detection of filter;
It can be used in bio safety, HVAC system, computer room, beverage packaging environment, medicine, medical equipment production environment, hospital clean operating room, automobile spraying environment, microelectronics, biochemical products, food hygiene, fine chemical industry, precision machinery, aerospace and other production and scientific research departments;
HVAC and pharmaceutical enterprises and their supervision and management departments implement GMP standards and electronic production enterprises.
Technical Parameters
Light source | Semiconductor laser, life over 35000 hours |
Sampling flow | 2.83L/min （0.1ft3） |
Display mode | Liquid crystal display (LCD), real-time display, last cycle display, real-time concentration display, time, date, measured value, temperature and humidity, room number, sampling point, sampling times, battery power, state and other parameters, 95% UCL calculation, can directly display particle concentration (particles / m3) |
Rechargeable battery | Lithium-ion battery, 7.4 V,2200mAh |
Power supply | AC power adapter, AC :100V~245 V,50/60 Hz to DC: 7.4 V,1 A |
working hours | 6 hours (remaining power indication) |
Counting mode | Cumulative value, difference value and concentration value |
Test mode | Single, continuous, remote |
Unit conversion | Units can be converted to m3 |
Particle size channel | 0.3, 0.5, 1.0, 3.0, 5.0, 10μm, and the six sizes are counted at the same time |
Sampling period | 1~10000(s) delay count: 0~99(S) self-cleaning time: ≤10 (min) |
Working environment | Temperature: 10~40℃ (50~104℉) Relative humidity: 20~90%RH, no condensation. Atmospheric pressure: 86-106KPa |
Temperature and humidity: | Optional (1) temperature: 0 ~ 50℃ 1℃. (2) humidity: 0 ~ 100% RH 5% |
UCL settings | Sampling points (a): set from 2 to 9 points. Sampling times per point: (L)2~9 times. Set measuring position: 0-999 |
UCL report | Comply with ISO14644-1, GB50073-2001, GMP and FS-209E standards |
Data storage | It can store 20,000 sets of data (circular buffer) (including particle size, data, environmental data, year, month, day, time, sampling amount and data location), and the data will not be lost after power failure. |
Communication interface | RS232,9600 baud rate |
Alarm settings | The instrument has a level alarm function, which can alarm that the battery voltage is too low after the clean room level 100, 1000, 10000, 10000 and 300000 exceeds the standard |
Zero count | Meet the requirements of JJG-547-88 dust particle counter verification regulation JIS B9921:1997, less than one every five minutes |
Overlapping error | 5 %,2,000,000 grains/cubic foot |
External Bluetooth printer | |
Dimension | 230×130×45(mm) |
Weight | 0.6kg |
Standard configuration | Suitcase/charger, isokinetic sampling head, zero filter, connecting cable, USB flash drive, external Bluetooth printer |
Optional items | Temperature and humidity sensor |
