SC-13011
Scince
Review
Test indexes: filter efficiency, resistance.
10 inch touch screen, human—computer interaction, intuitive display, easy operation.
Flow is adjustable, meet different test requirements of filter.
Install the filter element, press the test button, and the test will be carried out automatically.
Various configurations are provided to meet the test requirements of different filter elements, the fastest single test period is 18s.
Customize fixture for different HEPA.
Test results can be printed as labels for quality control.
High detecting sensitivity for leak source.
It can be designed as automatic feeding according to requirements, on—line testing can be realized.
Applications
Filter efficiency and resistance test of vacuum cleaner filter.
Filter efficiency and resistance test of filter for weeding machine.
Filter efficiency and resistance test of filter for air purifier.
Technical Parameters
Item | Parameter |
Aerosol | DEHS |
Air volume | 50~120m3/h |
Resistance range | 0~500Pa |
Detector | Laser particle counter |
Flow rate accuracy | ±2.5% |
Resistance accuracy | 1% |
Power supply | AC220V, 50 or 60 Hz |
Dimension | 700mm*650mm*1700mm |
